Catalog

Axial fans and server coolers

DC axial fans from 40 to 120 mm at 5–48 V, 120 mm AC fans at 110 / 220 / 380 V, and 1U–4U server coolers. Every model lists airflow, static pressure and noise.

All products
25 products
as2u-804-server-liquid-cooler-lga3647-v2
Server Liquid Cooler

RU2U-804 Server Liquid Cooler LGA3647 400W

2U server liquid cooler for LGA3647, rated 400W TDP. 476mm aluminium radiator with 24 FPI and dual 40mm blowers at 8000rpm, plus a graphite-bearing ceramic-shaft pump rated 5.6W at DC 12V. Screw mounting, S420 thermal grease included.

View product
as1u-406-server-liquid-cooler-200w-v2
Server Liquid Cooler

RU1U-406 Server Liquid Cooler 200W Intel and AMD

1U server liquid cooler rated 200W TDP, fitting Intel LGA775/115X/1366/2011/2066 and AMD FM1/FM2/AM2/AM3/AM4. 167mm aluminium radiator at 15 FPI with a 40mm blower at 8000rpm, plus a graphite-bearing ceramic-shaft pump rated 5.6W at DC 12V.

View product
ac-fan-120x120x38mm-v2
AC Fan

1238 AC Axial Fan 120x120x38mm 110V 220V 380V

1238 AC axial fan, 120 x 120 x 38 mm, the high-pressure mains fan in the range at up to 105 CFM and 8.13 mmH2O. Available at 110V, 220V and 380V with sleeve or dual ball bearing, for cabinets, transformers and industrial equipment.

View product
ac-fan-120x120x25mm-v2
AC Fan

1125 AC Axial Fan 120x120x25mm 110V 220V

1125 AC axial fan, 120 x 120 x 25 mm, running directly from mains at 110V or 220V, 50/60Hz. Sleeve or dual ball bearing. Typical use is cabinet exhaust, welding machines, transformers and air-conditioning equipment where no DC supply is available.

View product
dc-fan-120x120x38mm-v2
DC Fan

12038 Axial DC Fan 120x120x38mm 12V 24V 48V 2-Pin

12038 axial DC fan, 120 x 120 x 38 mm, the largest axial frame in the range at up to 199 CFM and 23.86 mmH2O. Used for cabinet exhaust, welding machines, battery racks and heavy equipment cooling. 12V, 24V and 48V in three speed grades, dual ball bearing.

View product
dc-fan-92x92x38mm-v2
DC Fan

9238 Axial DC Fan 92x92x38mm 12V 24V 48V 2-Pin

9238 axial DC fan, 92 x 92 x 38 mm. High-pressure 92mm frame delivering up to 111 CFM and 22.62 mmH2O, used on telecom racks, inverters and machine-tool cabinets. 12V, 24V and 48V in three speed grades, dual ball bearing, FG/RD and PWM options.

View product
dc-fan-80x80x20mm-v2
DC Fan

8020 Axial DC Fan 80x80x20mm 12V 24V 2-Pin

8020 axial DC fan, 80 x 80 x 20 mm, a deeper 80mm frame that holds airflow against filters and dense fin stacks. 12V and 24V in three speed grades, sleeve, hydraulic or dual ball bearing, FG/RD and PWM options, auto-restart protection.

View product
dc-fan-80x80x15mm-v2
DC Fan

8015 Axial DC Fan 80x80x15mm 5V 12V 24V 2-Pin

8015 axial DC fan, 80 x 80 x 15 mm, the most common 80mm depth for power supplies, chargers, projectors and enclosure ventilation. 5V, 12V and 24V in three speed grades, sleeve, hydraulic or dual ball bearing, FG/RD and PWM options.

View product
dc-fan-80x80x10mm-v2
DC Fan

8010 Axial DC Fan 80x80x10mm 5V 12V 24V 2-Pin

8010 axial DC fan, 80 x 80 x 10 mm, a slim 80mm frame for low-profile enclosures, AV cabinets and telecom shelves. 5V, 12V and 24V in three speed grades, sleeve, hydraulic or dual ball bearing, FG/RD and PWM options, auto-restart protection.

View product
dc-fan-70x70x20mm-v2
DC Fan

7020 Axial DC Fan 70x70x20mm 12V 24V 2-Pin

7020 axial DC fan, 70 x 70 x 20 mm. A 70mm frame with enough depth to hold pressure in ducted paths, used on power supplies, servo drives and cabinet ventilation. 12V and 24V in three speed grades, sleeve, hydraulic or dual ball bearing, FG/RD and PWM options.

View product
Page 1 of 3
